E Type Rail Elastic Clip for Railway
The emergence of E Type Rail Elastic Clip for Railway has completely changed the way of welding fixed rails in the past, providing more possibilities, higher efficiency and safety guarantee!
- Product Introduction
The E-type rail elastic clip is a hot-rolled, spring-steel fastening component that delivers a controlled toe load to the rail foot, maintaining track gauge and resisting longitudinal creep. Engineered for concrete-sleeper and slab-track systems, the "E-clip" is the most widely specified clip in EN, AREMA, and Chinese TB networks. Lanling's version is vacuum-quenched and stress-peened for 3 million load cycles without fatigue fracture-ideal for heavy-axle-load freight (>35 t) and 350 km/h passenger lines.
Technical Specifications
| Diameter | E-clip Ø 16mm, Ø 18mm, Ø 20mm, etc. |
| Weight | Between 0.43kg/pc and 0.80kg/pc |
| Material | 65Mn, SUS304, spring carbon steel, high-strength carbon steel, etc. |
| Surface Treatment | Plain Oiled, Oxygen Black, Zinc Plated, Hot Dip Galvanized, Dacro coating, Color Painting |
| Hardness | 42–48 HRC |
Product Advantages
✔ Consistent clamp force
✔ Long maintenance interval
✔ Fast install
✔ Corrosion options
✔ Quiet operation
✔ Green supply
Product Quality
Every E-clip undergoes 100% magnetic-particle inspection, and each production batch is rigorously fatigue-tested on a 100 kN servo-actuator to ensure consistent performance. Each clip is laser-marked with a heat number and QR code, enabling full traceability, and quality certificates are made available to clients through our secure portal before shipment.
Packaging & Shipping
With customers in both domestic and international markets, our product packaging is designed to meet the requirements of long-distance transportation. We use wooden crates, steel pallets, and woven bags to ensure moisture resistance and impact protection during shipping. Packaging solutions can also be customized according to shipment volume and specific customer requirements.
